AT150R3-ATEX
The AT150R3-ATEX is a SmartPOS designed for hazardous and regulated environments where intrinsic safety is required. Certified to PCI 5 and compliant with ATEX requirements, it enables secure payment acceptance in locations such as fuel stations and other potentially explosive atmospheres, while maintaining the usability and deployment flexibility of a standard retail SmartPOS.
FEATURES
- SmartPOS designed for hazardous and regulated environments
- ATEX certified for use in potentially explosive atmospheres
- 5” touch display
- PIN on glass technology
- Designed for fixed and attended payment operations
- Suitable for fuel stations and other safety-critical retail locations
- Built for stable operation in demanding deployment conditions
- PCI PTS 6.x
APPLICATIONS
-
Petrol Station
CERTIFICATIONS
- PCI PTS 5.x with SRED
- GBIC, and CC compliant
- EMV Contact L1 & L2
- EMV Contactless L1
- Mastercard TQM (IFM/PCD)
- PayPass, PayWave, DPAS, ExpressPay, UnionPay
- CE
- CB
- FCC
OPTIONAL PERIPHERALS
- Holster
- Silicone Protective Case
| CPU | - ARM Cortex-A7 Quad Core 1.1GHz |
| OS | - Android 8 |
| Memory | - 1GB DDR3 SDRAM / 8GB eMMC Memory |
| Display | - 5" TFT (1280x720) with capacitive touch display |
| Encryption PinPad | - TOUCH PINPAD |
| Card Slot | - SAM*2 / SIM (Optional for 4G feature) |
| Magnetic Card Reader | - ISO 7811 compliant. 3-track MSR |
| Smart Card Reader | - ISO7816-1/2/3 compliant asynchronous card protocol T=0, T=1 |
| Contactless Card Reader |
- ISO14443 type A/B, Mifare - PayPass, PayWave, DPAS, ExpressPay, UnionPay - NFC (ISO18092) |
| Audio | - Mono Speaker |
| Printer | - 48mm width printer with tear bar |
| Barcode Reader (Optional) | - Support 1D/2D barcode scanning |
| Wireless Communication |
- WI-FI 802.11 a/b/g/n - Bluetooth 4.2 BLE - 4G wireless, SIM x2 (option) |
| Peripheral Ports | - USB type C * 1 |
| Security |
- Algorithm: 3DES, AES, RSA, FPE(AES FFX) - Key management: MK/SK, DUKPT - TLS 1.2 support - Secure program and parameter load |
| Environmental |
- Operating Temperature: 0°C to 50°C - Battery Charging Operating Temp.: 0°C to 45°C - Storage Temperature: - 20°C to 55°C - Operating Humidity: 5% to 85% (non-condensing) - ATEX certified: II 3G Ex ic IIB T3 GC |
| Power Supply |
- Switching Power Adapter 5V/2A - Li-Ion Battery |
| Power | - 5V / 2A DC |
| Dimension (mm) |
- 186(L) x86 (W) x 65(H) mm * Terminal body thickness 38mm |
