Secure Unattended Outdoor Pin Entry Device
XAC's SPED5 Unattended Secure Payment PINPAD module provides flexibility for easy integration into various self-service applications like gas pumps, vending machines, parking meters, kiosks and a multitude of other outdoor transaction solutions.
SPED7 (PCI 7) to be available in 2025 Q4.
#hypermarket #grocerystore #chainstore #foodcourt #parkinmeter #gasstation
#bank #atm
#bank #atm
| CPU | 32-bit ARM Cortex M0 (72MHz) |
| OS | RTOS |
| Memory | - NOR Flash 4MB |
| Keypad | - 4x4 metal keycap - Number key x10 (0~9) - Function key x 4 - Vandalism protection IK10 rating |
| LED | Tricolor LED for different device status |
| Extension Port | - USB type A or RS232 COM |
| Security | - Algorithm: 3DES, AES, RSA - Key Management: MK/SK, DUKPT - Secure Code Update Architecture - Mutual Authentication - Message Encryption - Removal Protection |
| Environmental | - Operating Temperature: -20°C to 70°C - Storage Temperature: - 30°C to 70°C - Operating Humidity: 5% to 95% (non-condensing) - IK10 impact resistance - IP rating: IP65 (Front side) / IPx2 (Rear side) |
| Power | - 5V / 500mA |
| Dimension (mm) | 115(L)x 96.4(W)x 30(H) mm |
- CE
- FCC
- ROHS/WEEE/REACH
- FCC
- ROHS/WEEE/REACH
| # | Description | File Name |
|---|---|---|
| 1 | SPED5_EPP_Product Datasheet | DOWNLOAD |
