Secure Unattended Outdoor Contactless Reader
xNFC_C150-SE Contactless Reader Module is designed to be used in kiosk/Self service applications for accepting EMV/non-EMV contactless cards.
► Support for the latest NFC (ISO18092) and ISO14443 type A/B standards
► PCI 6.0 certified
► Support for 2 SAM slots
► USB 2.0 or RS232 communication interfaces
► A user-friendly interface in a small compact design which makes it easy to integrate into the mechanical design of most kiosks
#gaspump #parkingmeter #vendingmachine #billpaymentkiosk #hospital
| CPU | ARM CORTEX M3 secure processor Supports Program and Parameter updates |
| Card slot | SAM x 2 |
| Contactless Card Reader | 4 LED sequence indicators ISO 14443 type A/B NFC: ISO 18092 Mifare Felilca EMV Contactless L1 Contactless Payment Schemes: Paywave | Paypass | DPAS 2 | ExpressPay | CUP | J-Speedy | Interac Flash Device firmware programmable with upgrade capability |
| Audio | Buzzer |
| Peripheral Ports | USB 2.0 full speed x 1 RS232 x 1 |
| Environmental | Operating Temperature : -40°C to 70°C Storage Temperature : -40°C to 85°C Operating Humidity : 5% to 95% RH (non-condensing) IP65 rating (for Outdoor and Rugged models) IK10 impact resistance Material complies with NFPA130(Option) |
| Power | 5VDC± 5% @ 500 mA |
| Dimension (mm) | 78mm (W) x 100mm (H) x 35mm (D) Portrait and Landscape models |
| Compliance Approval | PCI PTS 6.0 |
| Regulatory Approval | CE FCC UKCA |
| # | Description | File Name |
|---|---|---|
| 1 | xNFC_C150-SE Contactless Reader Module | DOWNLOAD |
