CPU/SoC	System:MT8766 Quad-Core A53 Secure: STM32U ARM Cortex-M33 SoC
OS	Android 14
Memory	- 2 GB SDRAM +16 GB eMMC Optional - 4 GB SDRAM +64 GB eMMC
Display	- 3.5” 640x960 full color TFT IPS - Capacitive Touch (PIN Entry)  - Auto adjustable brihtness
SCR	- EMV L1 approval (T=0 & T=1 type) - Support up to 2 SAM slots (Optional) - Card slot with LED light guide
CTLS	ISO14443 type A/B ISO18092 (NFC) MiFare        Sony Felica
Barcode Reader/Camera	- 0.3MP fixed-focus front camera
Wireless Communication	Built-in Wifi 802.11 a/b/g/n/ac (2.4GHz & 5GHz) Bluetooth 5.0 Dual mode 4G LTE (optional external antenna) GPS (optional external antenna)
Peripheral Ports	- USB2.0-A x2 - USB2.0-C x1 - COM RJ12 x1  - Ethernet 10/100 RJ-45 x1 - MDB Slave x1
Audio	- Mono Speaker  - 3.5mm headset jack x1
Power Supply	12V/2A input Host wake-up on card insert (Optional)
Dimension (mm)	- 110 (L) x 77 (W) x 45 (D) mm (Support Portrait & Landscape Mounting)
Weight (gm)	~350g
Environmental	Operating Temperature: - 30°C to 70°C ­Storage Temperature: - 40°C to 75°C ­Operating Humidity: 5% to 95% (non-condensing)

Security Certification
- PCI PTS 6.x with SRED
- GBIC, and CC compliant
- EMV Contact L1 & L2
- EMV Contactless L1
- Mastercard TQM (PCD/IFM)
- PayPass|PayWave|DPAS|ExpressPay|China UnionPay|JCB J-Speedy
- Google Pay, Apple Pay, Samsung Pay, Apple Pay VAS, ECP2, Google Smart Tap

Safety
- FCC | CE | CB | cTUVus
- ROHS/WEEE/REACH
- IP65 | IK08 compliant
- High durability UV proof rated plastic
